There's no special configuration required for your mobile device, this option works straight out of the
box.

Wireless quick start

1. Connect the DiGidot C4 to a power source. Read chapter 'Connecting power' or choose one of
following options:
Option 1 Connect DC+ and DC- to a switching power supply, rated 5Vdc up to 24 Vdc, that is able to
output at least 5 Watts
Option 2 Connect the DC Socket, located next to the Ethernet ports to a 5 Vdc power source (USB
port).
2. Press and hold the on board button for 10 seconds to turn on the Wi-Fi. This will automatically
setup your DiGidot C4 as a temporary access point. The status LEDs of the DiGidot C4 will turn blue-
white when the access point is activated. The access point wil be closed again after startup/reboot,
unless you configure it permanently on the Wi-Fi settings page.
Go to: Home > Settings > Network > Wi-Fi tab.
3. Install the free DiGidot app on your mobile device (this is optional) or go to step 4.
4. Connect your mobile device or computer to the DiGidot C4 Wi-Fi Network. Available DiGidot C4
networks are listed with their MAC Addresses, as shown on the DiGidot C4 product label for easy
identification, E.G. "DiGidot C4 - 13:5C".
5. Start the DiGidot C4 app or open your internet browser and access your device(s) by browsing to
http://172.16.0.1.

Device network settings for Art-Net

The device network settings can be changed in the integrated user interface. This is required in case
you want to communicate with an Art-Net control device.
1. Log into user interface
The DiGidot C4 has a Built-in web-based user interface which you can access by using a web
browser.
Once you have configured the IP settings on your computer, you can access the DiGidot C4 interface.
Open your web browser, type http://10.254.254.254 in the address bar and press enter.
2. Configure device name and network settings
Home > Settings > Network.
You can change the IP Address and subnet mask of the DiGidot C4. The IP Address needs to be
unique in your network to avoid IP conflicts.
The device name than will be shown in the network can be changed on this page on this page:
Home > Settings > Device page
