connected line between the two items.
Parameters that can be controlled by linked triggers are:
Speed
Hue (color)
Saturation
Brightness
Playlist
OSC
OSC commands must be send to port 8000
‣
UDP
UDP commands must be send to port 6467
‣
Further information about OSC and UDP triggers can be found here: Home > Triggers > click on the
3 dots in the top right blue bar > select 'HTTP, UDP and OSC' and select the desired protocol tab.
For some of these parameters it's possible to define a specific control range by adjusting the sliders.
For the analog, Art-Net and DMX inputs it's required to set a minimum and maximum input value.
Some triggers and some actions require further configuration, such as OSC and UDP where custom
messages can be set.
NOTE: The amount of triggers that you can generate is limited due to available memory. Available
memory is affected by the license, amount of configured universes, amount of actions, scenes that
are playing, etc. In any case, the maximum amount of triggers is around 25. If too much triggers are
created, this can result in memory overload and will cause a device crash. In such cases, it's best to
remove the microSD card, make a copy of the microSD card, delete the contents of the triggers folder
and insert the microSD card again. New triggers can be created but you should create less triggers
than before.
Trigger watcher
Home > Triggers > Click the three dots in the top right blue bar > Trigger Watcher
The trigger watcher can be used to monitor trigger activity.
There are three tabs, 'ALL TRIGGERS', 'UDP MESSAGES' and 'OSC MESSAGES'. Select the the trigger
tab that you want to monitor and click 'START WATCHING' all the trigger activities will be listed.
If you want to clear the screen Click 'CLEAR LOG' any time.

Groups

Home > Groups
This function allows you to create specific groups of DiGidot C4 controllers. This makes the
configuration, identification, testing, restarting and organizing specific parts of your project or
installation a lot easier. (This feature is still in development and will be updated in the future.)
