Record options

Time based
Adjust the start and end time to trim the record to its desired length.
Frame based
Adjust the start and end frame trim the record to its desired length.
Find loop
This option detects if there is a loop in the record (within the trimmed section) and automatically
creates a looped record.
Trim black
This option detects if there are any black frames at the beginning and end of the trimmed selection
and trims the length of the entire record.
No effect
This will keep the original trimmed record.
Fade
This option creates a fading transition from the end to the start of the record. You can manually
adjust the fading time before the record is saved.
Note that this option only appears when the record is long enough to generate this effect.
Pingpong
This option replays the trimmed record from beginning to end and then from the end to the beginning
again.

Recording DMX

In order to record from DMX you have to configure one or two DMX Input(s) in the I/O configuration.
Go to Home > Settings > In/out configuration > Select a port and choose 'DMX Input'

Record settings

Home > Create scenes > Record settings
On this page you can select and deselect the incoming universes that can be recorded.
Use Art-Net to start, stop and save records
This option allows you to trigger following record functions: prepare record buffers, start, stop and
save records with an Art-Net signal.
To create an Art-Net trigger you need to specify a universe number, a channel number and a
minimum and maximum DMX/channel value between 0 and 255, to determine when when the event
should be triggered. These triggers can also be created manually on the Home > Triggers page.
