The I/O ports can also be configured as 4 x DMX TTL which can be converted to four balanced DMX
outputs when a DiGidot PxLNet Transmitter module is connected to the DiGidot C4.
Art-Net IP Address filter
With this feature you can configure the DiGidot C4 to only listen to a specific IP Address as input.
Signals from other IP Addresses will be ignored.
Art-Net routing
You can route any of the incoming Art-Net universes to the DMX or Art-Net outputs.
HTP merge signal inputs
It is possible to merge various input signals such as DMX and/or Art-Net according to the HTP
(Highest Takes Precedence) principal.
Art-Net & DMX Monitor
The Monitor is a powerful tool where all incoming and outgoing data as well as frame rate and
network status can be monitored.
Create segments
Create simple chase effects for large amount of pixels by creating segments of channels or LED's and
reduce the amount of input channels.
Daisy-chainable
The two port ethernet switch with RJ45 bus allow the DiGidot C4 to be daisy chained. Daisy chaining
more than 5 devices can cause network delays. Therefore we recommend to use a professional grade
Gigabit network switch to split the network load.
Build-in scene generator (DiGidot C4 Extended only)
You can generate simple static or color scroll scenes in the user interface, store them and activate
them by any trigger option.
Scene recording from Art-Net or DMX (DiGidot C4 Extended only)
The record function can be used to record Art-Net or DMX streams and store them as recorded
scenes.
Scene triggering by various digital or analogue control inputs (DiGidot C4 Extended only)
Recorded scenes can be triggered by a huge amount of analog and digital triggers, such as 0-10V, dry
contacts, on board push button, build-in timer, HTTP Get, UDP, OSC, Art-Net, DMX, etc.
On board Wi-Fi
The DiGidot C4 features onboard Wi-Fi for convenient wireless access through the free DiGidot app
or when accessing through the web interface. Wi-Fi can also be used for triggering.
We discourage sending Art-Net over Wi-Fi, because it can be unstable and reliable, but it is possible.
Gamma correction
This is a function to correct the light intensity, luminance or brightness of the input. This amount of
gamma correction changes not only the brightness, but also the ratio of red, green and blue.
