2. Enter an OSC Address manually
> Enter the same Address that is used by to the OSC app or software.
After saving the OSC trigger it will be listed in the Triggers overview. Use the copy button in the trigger
item to copy the OSC command and paste it to your software program.
Address for OSC editor
If an OSC Address has been entered in the trigger first, the same Address needs to be copied in the
OSC editors address field (deselect 'Auto' in TouchOSC).
We recommend however to create the OSC interface first, then create the triggers and use the learn
function automatically copy the OSC addresses that are associated with the OSC interface buttons
and sliders.

UDP

Home > Triggers > select '+' to add a trigger > select 'UDP'
UDP is a small message send over the network port. The DiGidot C4 can receive UDP messages. This
can be useful if other software needs to control the DiGidot C4 controller. UDP is mostly used by
developers. Downside of using UDP instead of HTTP is you will not get a conformation if you send a
message, but UDP has slightly better performance.
Enable UDP trigger
In order to be able to create UDP triggers, it must be enabled first. This can be done by creating a
UDP trigger and press the 'enable' link or do the following steps:
1. Go to:
Home > Triggers > click on the 3 dots in the top right blue bar > select 'HTTP, UDP and OSC'
2. Enable the OSC triggers option and click the 'save' button.
Add a UDP trigger
Home > Triggers > select '+' to add a trigger > select 'UDP'
A UDP trigger can be created in two ways.
If..
1. Learn an incoming UDP message
Press the 'LEARN' button and send the message from an UDP app or software.
‣
Note that the UDP sending application must be connected to the C4 network.
2. Enter an UDP message manually
Enter the same message that is used by to the UDP app or software.
‣
After saving the UDP trigger it will be listed in the Triggers overview. Use the copy button in the trigger
bar to copy the UDP command and paste it to the desired destination.
