Art-Net/DMX controller required

In order for the DiGidot C4 to work in a live system setup or to be able to record scenes (DiGidot C4
extended only), a third party Art-Net/DMX software or console is required. The DiGidot C4 controllers
are known to be working with various professional grade softwares and consoles, such as: MADRIX,
Pharos, ArKaos, Resolume Arena, MadMapper, POET, grandMA and many more. As long as the control
software or console uses industry standard Art-Net or DMX protocols, you can control the DiGidot C4
controller.
Control software, DMX & Art-Net control platforms
When the setup process has been completed, the DiGidot C4 is ready to be used with any type of
Art-Net/DMX software/device.
The DiGidot C4 can automatically be detected as an Art-Net device, depending on the software or
console. In order to do so, an Input/output configuration must be completed first.
Each DiGidot C4 can be configured to have a unique IP address for unicasting. Assign a device name
to the DiGidot C4, for easier recognition (see the chapter Configuring the DiGidot C4).

Supported protocols (ICs)

The DiGidot C4 supports more than 60 'Data' and 'Clock+Data' SPI protocols.
All supported protocols can be found in the C4 user interface. Go to Home > Settings > In/out
configuration > Select a port drop down menu to open the protocol list.
Please visit our website www.digidot.eu for latest overview of all supported protocols/IC's.
For a more technical protocol overview and their performances, please check our DiGidot C4
Performance Guide on this web page: https://digidot.eu/support/documentation

Key features explained

The DiGidot C4 has many powerful features, in this chapter we will explain what these key features
do.
More than 55 supported protocols
The DiGidot C4 supports more than 60 control protocols and new IC's are added frequently.
Up to 16 universes Art-Net to SPI conversion*
Depending on your DiGidot C4 version and license, you can output up to 16 universes, equaling 8192
control channels.
Art-Net In/Out
The onboard 100Mbit switch allows for an Art-Net input and output.
DMX In/Out
The four I/O ports can be configured as one or two DMX inputs or outputs. It's also possible to use
one input and one output.
