VARIOUS

Online resources

For technical specifications, latest documentation, manuals, product information, support and
upgrades, please visit www.digidot.eu.

Remarks

We've put great care in writing this manual. However, in case you encounter any discrepancies or
unclarities, please contact us. This manual and feature specific instructions are based on firmware
and interface versions mentioned in the chapter 'Manual version'.
NOTE: This manual cover information for the DiGidot C4 Live and Extended controllers. In case
of C4 Live controllers, some of the features may not be displayed in the user interface because
they are limited to the Extended version only (refer to appropriate symbols in this manual).

Terminology

SPI
IC
IC/SPI protocol
Scene
Playlist
Action list
Universe
I/O configuration
DMX
C4 Manual
Serial Peripheral Interface: this is an interface bus between that is used to
send data between microcontrollers and IC's.
Integrated Circuit: this is an electronic component which houses a
readymade circuit that is able to perform one specific task. An IC can be
placed separately on a PCB or integrated in a LED package to control/drive
a LED or segment/array of LEDs.
Type of control protocol that is used by an IC.
A scene can also be referred to as a cue and can contact static and
dynamic values that control specific channels.
A playlist consists of multiple scenes that are played in a specific order
according to pre-programmed parameters.
A sequence of actions triggered by only one trigger.
Typically, a universe is referred to as one DMX control network consisting
of 512 control channels, also typically associated with one DMX output.
DiGidot also refers to a universe as one set of 512 control Channels that
belong to specific Art-Net, sACN or DMX universes. But when we mention
more than one universe on one output for example, we always refer to
them as amount of control channels and not necessarily as DMX
universes.
Input/Output configuration, determines how and which signals the C4 is
controlled by and how the ports of the C4 are configured.
Digital MultipleX is a universal lighting control protocol which is
standardized by USITT and ESTA/Plasa.
