DiGidot C4 Manual page 52

Port D1 is set to DMX out and will automatically be combined with port D2, because 2 data lines for a
(balanced) DMX signal are required. You can now select a protocol for D3+D4.
Art-Net redirects
Art-Net universes universes/channels can be redirected to other Art-Net universes. In this case the
the second RJ45 network port will become the Art-Net output.
Click the '+' button to add Art-Net universes that need to be redirected.
Select the input universe that needs to be redirected and select the output universe on which this
universe needs to broadcasted and enter the amount of channels that need to be redirected. The
default starting channel is 1.
Select the 'Advanced settings' for more universe specific settings such as the starting address, IP
address of the Art-Net source, 16 bit input and other output options, etc.
Art-Net redirects are considered as output channels and will affect licensed channels.
This also means that you can record an Art-Net stream and play it back using Art-Net. Recorded
universes can outputted on different output universes, defined in the Art-Net redirect.
NOTE: The DiGidot C4 starts to count universes at 0 (zero)! Some softwares or consoles, such as
MADRIX may start counting at universe 1.
TIP: Additional tools available!
In the right top menu you will often find additional tools under the three dots in the top right blue
bar.
Autocomplete configuration
Use this tool to copy the configuration of the first port of the first device to a the selected ports/
devices. The interface will show various autocomplete options, depending on your system setup.
Global configuration
This page offers advanced configuration item options that apply to all selected devices.
Such as;
Gamma Correction
‣
Color profile
‣
Fallback options
‣
IP Address filter
‣
Input watcher
The input watcher is a useful tool that monitors incoming control signals. You can switch between:
Art-Net: you can select a specific universe that you want to monitor
‣
DMX: switch between the inputs if you have configured one or more ports as DMX In.
‣
Limit outputs
On this page you can set the master brightness, the brightness limiter and the adaptive power limiter.
Brightness limiter
‣
