message increases when powering the DiGidot C4 from the end of the LED product(s) and when more
LEDs are turned on. Please check the voltage at the screw terminal of the DiGidot C4 and re-apply
power or change your wiring if necessary.
TIP: There are some 'hidden' menus available in the interface and DiGidot app, which can be
accessed when pressing a button or slider for about one second.
E.G.: On the 'Scenes' page, when playing a scene, you can maximize the player bar (page bottom
right). This will show three sliders for Speed, Hue and Brightness. When pressing the slider bars, an
extra screen with additional options will appear.

ACCESSORIES

DiGidot offers various accessories for your installation.
Please contact your DiGidot reseller to order other following DiGidot products.

Transmitter and receiver modules

DiGidot PxLNet Transmitter
Art. no.: 20342
Operating voltage: 12-24Vdc
‣
Converts up to four unbalanced SPI signals to PxLNet to transmit over large distance up to
‣
250 meters (requires DiGidot receiver modules)
Converts four DMX TTL signals to four balanced DMX outputs
‣
Inter connects all grounds
‣
DiGidot PxLNet Transceiver
Art. no.: 20344
Operating voltage: 5-24 Vdc
‣
Two operating modes:
‣
Receiving mode: Converts PxLNet to the original SPI protocol
‣
Transmitting mode: Converts SPI protocol to PxLNet
‣
Can directly be soldered to the beginning or end of most SPI controlled LED strips
‣
RJ45 bus and solder pads for signal input
‣
DiGidot TRRS Trigger Cable
Art. no.: 20903
Optional cable to connect 3 analogue trigger inputs to DiGidot C4 Extended
‣
1 meter in length
‣
DiGidot RJ45 Network Cable
Art. no.: 20330
RJ45 Network cable for connecting and daisy chaining DiGidot C4 (included with DiGidot C4
‣
Extended)
