TECHNICAL SPECIFICATIONS

Electrical
Input Voltage:
Max. power consumption:
Mechanical
Housing material:
Dimensions:
Net device weight:
C4 Live package weight:
C4 Extended package weight:
Mounting:
Environmental
Operation Temperature (Tc):
Max. ambient Temp. (Ta
max
Storage temperature:
Max. operating relative humidity:
Protection
IP rating:
Power:
Digital input / output:
Analog input:
Control
Input Protocols:
Output Protocols:
Output channels (of 4 I/O ports):
Ethernet:
Wi-Fi:
Wi-Fi protocols:
Frequency range:
TX Power:
Antenna:
Wi-Fi Mode:
Wi-Fi security:
Encryption:
C4 Manual
5-24V DC
5W
Self extinguishing Acrylonitril-Butadieen-Styreen (ABS)
153 x 74 x 28 mm | 6.02 x 2.91 x 1.10" (L x W x H)
140gr | 4.93oz
265gr | 9.34oz
280gr | 19.87oz
DIN-rail or surface mounted
0 to 50°C | 32 to 122°F
): 40°C | 104°F
-20 to 50°C | -4 to 122°F
90% (indoor use only)
IP10
Reverse polarity
Overvoltage protection (max. 24Vdc)
Overvoltage protection (max. 12Vdc)
Art-Net 1,2,3 & 4
DMX512 (2 inputs)
DiGidot C4 app
Art-Net 1, 2, 3 & 4 (out/through)
DMX512 (2 outputs)
DMX TTL (4 outputs)
55+ SPI protocols (check supported IC's list)
UDP (DiGidot C4 Extended only)
OSC (DiGidot C4 Extended only)
Up to 8192 Art-Net channels or 1.024 DMX channels
(license dependent). Physical port limit: 4096 channels.
RJ45 compatible, for 10/100 Base-TX Ethernet
10/100 Base Ethernet with static IP Address or DHCP
802.11 b/g/n (HT20)
2.4 GHz ~ 2.5 GHz (2400M ~ 2483.5M)
Max. +20 dBm
Onboard
Client + AP
WPA, WPA2
WEP/TKIP/AES
