Rearrange the LED color order, for example from RGB to BGR. You can select a few standard
conversion profiles or create your own Custom profile. This might be required for some LED products.
The DiGidot C4 uses the default color order from the technical documentation of a selected IC/SPI
protocol.
Fallback color
This function allows to select a color that will be send to all output channels as soon as no Art-Net
signal is detected.
Color
Enter a RGB value between 0 and 255 per LED channel or use the color picker to select a color
easily. If you use the color picker, you can also adjust the saturation and brightness by
adjusting the sliders underneath. After selecting the fallback color, hit the ✓ button in the
center of the color picker to confirm your selection.
Timeout
Enter a delay/timeout in ms (milliseconds) when the fallback color becomes active after signal
loss.
Advanced input
Further universe specific settings can be changed;
Only accept Art-Net from IP Address: enter a dedicated IP address that this universe listens
‣
to.
Analog dimming: select one of the three analog inputs that will control the overall brightness
‣
of this IO configuration item.
16 bit input: When sending 16 bit data to the DiGidot C4, two input channels are used for one
‣
color channel. If your IC does not support 16 bit and you want to convert 16 bit to 8 bit, please
enable this option. If your input is 16 bit and your IC is too, it will be done automatically.
Second input (HTP merge): This wil merge the selected universes together and transmit the
‣
merged signals to the designated output. Enter the desired universe, start channel and the
amount of channels you want to merge.
Advanced output
Output options:
Bypass master dimmer: Enable if you want this output not to be dimmed by a master
‣
dimmer or brightness trigger.
Max time until resend: When no Art-Net is received within a given time the current output is
‣
resent to the IC's (LEDs). This is used to prevent data issues and IC timeout functions from
happening because some IC's will switch to a default color or sequence when no SPI is
received for a certain duration. This may also results in a decrease of frame rate (FPS).
Reset this value to its default by pressing delete > generate a new universe again by
selecting the blue + button of the specific D port.
When you are finished adjusting the advanced options, click 'save' to store the settings.
TIP: In order to quickly test your outputs you can toggle all ports on to full white when clicking the
bulb icon.
