Generate Scene (Digidot C4 Extended Only) - DiGidot C4 Manual

Prepare buffers:
Start record:
Stop Record:
Save record:
NOTE: Art-Net triggers can be used without the use of the DiGidot C4 interface or app.
Fixed frame rate
If fixed frame rate is enabled (default) the DiGidot C4 will record at 62 fps. If the option is disabled,
the DiGidot C4 will create a frame for each Art-Net/DMX message, this can be useful when your
software is sending at a fixed frame rate for example. Please note that higher fps rates result in larger
scene files and thus affects available memory. In most cases we recommend using fixed frame rate.
Select/deselect all
This option allows you to select or deselect all available input universes.
Select inputs to record
Check the universes that you want to record with your next recording.

Generate Scene (DiGidot C4 Extended only)

Home > Create scene > Generate scene
Scenes are generated based on one universe and are being copied to following universes and
outputs, depending on your I/O configuration.
You can generate three types of scenes, such as:
Static color
This will generate a static color scene.
Enter a RGB value from 0-255 or click on the color picker button to open the color picker page. As
soon as the color picker was selected, the current color value will be displayed on all output ports
(this can be switched off by unchecking the preview checkbox. Press and hold the color wheel and
move around until you've found the desired color, release the color picker to set the color.
Adjust the saturation and brightness (when using RGBW color profiles the Saturation slider will fade
in white and fade out color channels after 50% towards the unsaturated side (moving to left). In order
to select the white channel only, the saturation must therefore be set to 0.
Five color presets can be stored or on both sides of the color picker by pressing and holding the
preset buttons.
When the desired color is selected, press the check button in the middle of the color picker to
confirm.
C4 Manual
This will prepare the DiGidot C4 before recording.
This is required before starting the record. We recommend preparing record
buffers 1 second before starting to record.
This will start recording. The status LED will become white/blue.
This will stop recording. StatusLED will stop being white/blue.
This will save the record and will create a scene.
The scene name will be generated automatically.
Version 2.1.5 34 74 -
