ACCESSORIES

DiGidot offers various accessories for your installation.
Please contact your DiGidot reseller to order other following DiGidot products.
Transmitter and receiver modules
DiGidot PxLNet Transmitter
Art. no.: 20342
Operating voltage: 12-24Vdc
‣
Converts up to four unbalanced SPI signals to PxLNet to transmit over large distance up to
‣
250 meters (requires DiGidot receiver modules)
Converts four DMX TTL signals to four balanced DMX outputs
‣
Inter connects all grounds
‣
DiGidot PxLNet Transceiver 2
Art. no.: 20353xx
‣ Operating voltage: 5-48 Vdc
‣ Two operating modes:
Receiving mode: Converts PxLNet to the original SPI protocol
‣
Transmitting mode: Converts SPI protocol to PxLNet
‣
DMX to DMX TTL conversion
‣
‣ Status LED indicators
‣ Signal range of 250 meters
‣ Can directly be soldered to the beginning or end of most SPI controlled LED strips
RJ45 bus and solder pads for signal input
‣
DiGidot TRRS Trigger Cable
Art. no.: 20903
‣ Spare cable to connect 3 analogue trigger inputs to DiGidot C4 Extended
1 meter in length
‣
DiGidot RJ45 Network Cable
Art. no.: 20330
Spare RJ45 Network cable for connecting and daisy chaining DiGidot C4 (included with
‣
DiGidot C4 Extended)
DiGidot USB Power Cable
Art. no.: 20331
Spare Power cable to connect DiGidot C4 to 5 Vdc USB port (included with DiGidot C4
‣
Extended)
DiGidot DIN-Rail Clip
Art. no.: 20902
‣ Optional DIN-rail Mounting Clip for DiGidot C4
C4 Manual Version 2.2.0 73-78
