Chapter 2. Installation

2.2 Unpacking

Before removing the PanaFlow HT system from the crate, please inspect the flowmeter. Each instrument manufactured
by GE Measurement & Control is warranted to be free from defects in material and workmanship. Before discarding
any of the packing materials, account for all components and documentation listed on the packing slip. The discarding
of an important item along with the packing materials is all too common. If anything is missing or damaged, contact
GE Customer Care immediately for assistance.
Please note that your PanaFlow HT system may come in one of the three common configurations as shown below or a
custom design system. Also, the electronics may be in a separate box from the meter body for a remote mount
configuration.
Figure 3: PanaFlow HT Configurations

2.2.1 Identification

The PanaFlow HT meter has up to three separate labels for identification, depending on configuration. The system can
be either mounted as a single unit (local mounting) or as two separate pieces (remote mounting).
2.2.1a XMT900 Transmitter Identification
Figure 4: XMT Transmitter Label (example)
