Chapter 2. Installation
2.5 Making Electrical Connections (cont.)
WARNING! Always disconnect the line power from the PanaFlow HT before removing either the front cover
or the rear cover. This is especially important in a hazardous environment.
1. Disconnect any previously wired power line from the unit.
2. Loosen the set screw on the wiring cover.
3. Place a rod or long screwdriver across the cover in the slots provided, and rotate the cover counterclockwise until it
comes free from the enclosure.
4. Install any required cable clamps in the appropriate conduit holes on the opposite side of the enclosure.
5. Note the labels inside the rear cover to assist in wiring the power and option connections.
Proceed to the appropriate section of this chapter to make the desired wiring connections.

2.5.1 Preparing for Wiring

Wiring any option set requires completion of the following general steps:
1. Disconnect the main power to the unit and remove the wiring cover.
2. Install a cable clamp in the chosen conduit hole on the side of the electronics enclosure and feed a standard
twisted-pair cable through this conduit hole.
3. Locate the terminal block shown in Figure 10 on page 11 and wire the option as indicated on the label inside the
wiring cover (see Figure 2.5 on page 11). Secure the cable clamp.
To meet CE Mark requirements, all cables must be installed as described in
4. If wiring of the unit has been completed, reinstall the wiring cover on the enclosure and tighten the set screw.
For more specific instructions on particular output configuration, proceed to the appropriate sub-section(s) that follow.
12
!ATTENTION EUROPEAN CUSTOMERS!
Appendix G, CE Mark Compliance.
