Appendix C. Modbus Map
Register Register (in
(in Hex) Decimal)
936 2358
938 2360
93A 2362
93C 2364
Display Integer Read Only
B00 2816
B02 2818
Log Integer Read Write
D00 3328
D02 3330
D04 3332
D06 3334
D40 3392
D80 3456
Log Integer Read Only
F00 3840
Analog Out 2 Real Read Write
1000 4096
1002 4098
1004 4100
1006 4102
1008 4104
100A 4106
Analog Out 2 Integer Read Write
1180 4480
1182 4482
1184 4484
1186 4486
1188 4488
Analog Out 2 Max Real Read Only
1600 5632
1602 5634
1604 5636
102
Table 10: XMIT Modbus Map (cont.)
Access
Level
Gen User Unit type for Actual volumetric of
totalize
0: for Metric, 1: for English
Gen User Unit type for Standard volumetric of
totalizer
0: for Metric, 1: for English
Gen User Unit type for Mass of totalizer
0: for Metric, 1: for English
Gen User Unit type for Density
0: for Metric, 1: for English
VIEWER Maximum TimeOut for DISPLAY
VIEWER Minimum TimeOut for DISPLAY
Gen User Log control / status
Gen User Log interval
Gen User Logging time
Gen User Number of variables to log
Gen User variable address array
Gen User Variable unit code array
N/A Number of records
Gen User Analog Out 2 Error Handling Value
Gen User Analog Out 2 Zero
Gen User Analog Out 2 Span
Gen User Analog Out 2 Test Value (Percent of
Span)
Gen User Analog Out 2 Base Value
Gen User Analog Out 2 Full Value
Gen User Analog Out 2 Operating Mode
Gen User Analog Out 2 Type
Gen User Analog Out 2 Measurement Register
Address
Gen User Analog Out 2 Error Handling
Gen User Analog Out 2 Unit code
VIEWER Maximum Analog Out 2 Error Handling
Value
VIEWER Maximum Analog Out 2 Zero
VIEWER Maximum Analog Out 2 Span
Variable Unit Group
18
18
18
18
18
18
18
13
13
18
18
18
18
8
8
8
12
18
18
18
18
18
18
18
8
8
8
Read Only/
Read Write Format
RW INT33
RW INT34
RW INT35
RW INT32
RO INT32
RO INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RO INT32
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW (IEEE 32 bit)
RW INT32
RW INT32
RW INT32
RW INT32
RW INT32
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
