2.3.2 Electronics Enclosure Location (Remote Mount)

The standard PanaFlow HT electronics enclosure is a powder-coated, aluminum, IP67 explosion-proof enclosure.
Typically, the enclosure is mounted as close as possible to the transducers. When choosing a site for remote mount
installation, make sure the location permits easy access to the electronics enclosure for programming, maintenance and
service. The maximum distance is 100 feet (30 meters).
Note: For compliance with the European Union's Low Voltage Directive (2006/95/EC), this unit requires an external
power disconnect device such as a switch or circuit breaker. The disconnect device must be marked as such,
clearly visible, directly accessible, and located within 1.8 m (6 ft) of the PanaFlow HT.

2.3.3 Cable Lengths

Locate the electronics enclosure as close as possible to the transducers, preferably directly on the flowcell. However,
GE can supply transducer cables up to 100 ft (30 m) in length for remote location of the electronics enclosure. If longer
cables are required, consult the factory for assistance.

2.3.4 Transducer Cables

When installing the transducer cables, always observe established standard practices for the installation of electrical
cables. Do not route transducer cables alongside high amperage AC power lines or any other cables that could cause
electrical interference. Also, protect the transducer cables and connections from the weather and corrosive
atmospheres.
