GE PanaFlow HT User Manual page 122

Register Register (in
(in Hex) Decimal)
8B04 35588
8B06 35590
8B08 35592
8B0A 35594
8B0C 35596
Composite Channel Real Max
A200 41472
A202 41474
A204 41476
A206 41478
A208 41480
A20A 41482
A20C 41484
A20E 41486
A210 41488
A212 41490
A214 41492
A216 41494
A218 41496
A21A 41498
A21C 41500
A21E 41502
A220 41504
A222 41506
Composite Channel Integer Max
A300 41728
A302 41730
A304 41732
A306 41734
PanaFlow HT User's Manual
Table 10: XMIT Modbus Map (cont.)
Access
Level
VIEWER Ch_2 Up +- Peak
VIEWER Ch_2 Dn +- Peak
VIEWER Ch_2 dynamic threshold on UP channel 12
VIEWER Ch_2 dynamic threshold on DOWN
channel
VIEWER Ch_2 # Errors of Last 16
VIEWER Maximum Composite Velocity
VIEWER Maximum Composite Volumetric
VIEWER Maximum Composite Mass Flow
VIEWER Maximum Composite Fwd Batch Totals 17
VIEWER Maximum Composite Rev Batch Totals 17
VIEWER Maximum Composite Totalizer Time
VIEWER Maximum Composite Sound Speed
VIEWER Maximum Composite Inventory Fwd
Totals
VIEWER Maximum Composite Inventory Rev
Totals
VIEWER Maximum Composite Inventory
Totalizer Time
VIEWER Maximum Composite Current
Correction Factor
VIEWER Maximum Composite Current Reynolds
Number
VIEWER Maximum Composite acceptable
operating temperature reading from
temperature sensor
VIEWER Maximum Composite Standard
VIEWER Maximum Composite Net Batch Totals 17
VIEWER Maximum Composite Net Inventory
VIEWER Maximum Composite SIL Analog Out
Drive Current
VIEWER Maximum Composite SIL Analog Out
Monitored Current
VIEWER Maximum Composite status bit map
VIEWER Maximum Composite SIL errors
VIEWER Maximum Composite most significant
error
VIEWER Maximum Composite Gate Input State
bitmap: 0: Open, 1: Closed
Variable Unit Group
18
18
12
18
20
1
9
2
20
17
17
2
18
18
15
14
17
8
8
18
18
18
18
Appendix C. Modbus Map
Read Only/
Read Write Format
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO INT32
RO INT32
RO INT32
RO INT32
113
