Diagnostic Parameters

The values for the diagnostic parameters immediately after initial installation of the meter and verification of proper
operation should be entered below. These initial values can then be compared to current values to help diagnose any
future malfunction of the system.
Parameter
Ch1 Velocity
Ch1 Soundspeed
Ch1 Transit Time Dn
Ch1 Transit Time Up
Ch1 Delta T
Ch1 Up Signal Quality
Ch1 Dn Signal Quality
Ch1 Up Amp Disc
Ch1 Dn Amp Disc
Ch1 SNR Up
Ch1 SNR Dn
Ch1 Active TWup
Ch1 Active TWdn
Ch1 Gainup
Ch1 Gaindn
Ch1 Error Status
Ch1 Report Error
Ch1 Peak Up
Ch1 Peak Dn
Ch1 Peak% Up
Ch1 Peak% Dn
Ch1 Error
PanaFlow HT User's Manual
Table 14: Diagnostic Parameters
Initial Current Parameter
Ch2 Velocity
Ch2 Soundspeed
Ch2 Transit Time Dn
Ch2 Transit Time Up
Ch2 Delta T
Ch2 Up Signal Quality
Ch2 Dn Signal Quality
Ch2 Up Amp Disc
Ch2 Dn Amp Disc
Ch2 SNR Up
Ch2 SNR Dn
Ch2 Active TWup
Ch2 Active TWdn
Ch2 Gainup
Ch2 Gaindn
Ch2 Error Status
Ch2 Report Error
Ch2 Peak Up
Ch2 Peak Dn
Ch2 Peak% Up
Ch2 Peak% Dn
Ch2 Error
