Appendix C. Modbus Map
Register Register (in
(in Hex) Decimal)
A036 41014
Composite Channel Integer Max
A100 41216
A102 41218
A104 41220
A106 41222
A108 41224
A10A 41226
A10C 41228
A10E 41230
A110 41232
A112 41234
A114 41236
A116 41238
A118 41240
A11A 41242
A11C 41244
A11E 41246
A120 41248
A122 41250
A124 41252
A126 41254
A128 41256
A12A 41258
A12C 41260
A12E 41262
A130 41264
A132 41266
A134 41268
116
Table 10: XMIT Modbus Map (cont.)
Access
Level
VIEWER Maximum Composite KFact individual
value
VIEWER Maximum Composite Reynolds
Correction
VIEWER Maximum Command to capture a new
set of signal files
VIEWER Maximum Composite Path
Configuration
VIEWER Maximum Composite Hardware
VIEWER Maximum Composite Software revision 18
VIEWER Maximum Composite UMPU board
VIEWER Maximum Composite max range of
command
VIEWER Maximum Composite Command
VIEWER Maximum Composite Which test to run 18
VIEWER Maximum Composite Service
VIEWER Maximum Composite Factory
VIEWER Maximum Composite User
VIEWER Maximum Composite AnalogOut
Command (for trim)
VIEWER Maximum Composite Sensor serial
number 1
VIEWER Maximum Composite Sensor serial
number 2
VIEWER Maximum Composite Tracking
Windows
VIEWER Maximum Composite MultiK Active
VIEWER Maximum Composite MultiK Type
VIEWER Maximum Composite MultiK Pairs
VIEWER Maximum Composite KV Input
Selection
VIEWER Maximum Composite System Command
(such as commit, accept, halt)
VIEWER Maximum Composite Enable Active
TW
VIEWER Maximum Composite FireLow/ Fire
High during fault
VIEWER Maximum Composite Analog output
selection
VIEWER Maximum Composite Calibration Mode
Selection
VIEWER Maximum Composite Base Frequency
for frequency Output
VIEWER Maximum Composite Span Frequency
for frequency Output
Variable Unit Group
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
6
6
Read Only/
Read Write Format
RO (IEEE 32 bit)
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
