GE PanaFlow HT User Manual page 126

Register Register (in
(in Hex) Decimal)
A136 41270
A138 41272
A13A 41274
A13C 41276
A13E 41278
A140 41280
A142 41282
A144 41284
A146 41286
A148 41288
A14A 41290
A14C 41292
A14E 41294
A150 41296
A152 41298
A154 41300
A156 41302
A158 41304
A15A 41306
A15C 41308
A15E 41310
A160 41312
A162 41314
A164 41316
PanaFlow HT User's Manual
Table 10: XMIT Modbus Map (cont.)
Access
Level
VIEWER Maximum Composite Frequency Output
Unit Selection
VIEWER Maximum Composite Frequency Output
Error State Selection
VIEWER Maximum Composite Path Error
VIEWER Maximum Composite Unit Type
Dimension
VIEWER Maximum Composite Unit Type Density 18
VIEWER Maximum Composite Unit Type Mass
Flow
VIEWER Maximum Composite Unit Type
Volumetric
VIEWER Maximum Composite Unit Type
Velocity
VIEWER Maximum Composite test frequency for
frequency output
VIEWER Maximum Composite Sensor serial
number 3
VIEWER Maximum Composite Sensor serial
number 4
VIEWER Maximum Composite Sensor serial
number 5
VIEWER Maximum Composite Sensor serial
number 6
VIEWER Maximum Composite
Flowmeter/System serial number
VIEWER Maximum Composite Unit Type Time
VIEWER Maximum Composite Unit Type
Viscosity
VIEWER Maximum Composite Unit Type
Standard Volumetric
VIEWER Maximum Composite Standard BWT
buffer 1 serial number
VIEWER Maximum Composite Standard BWT
buffer 2 serial number
VIEWER Maximum Composite Standard BWT
buffer 3 serial number
VIEWER Maximum Composite Standard BWT
buffer 4 serial number
VIEWER Maximum Composite Standard BWT
buffer 5 serial number
VIEWER Maximum Composite Standard BWT
buffer 6 serial number
VIEWER Maximum Composite UMPU receiver
serial number
Variable Unit Group
18
18
18
18
18
18
18
6
18
18
18
18
18
18
18
18
18
18
18
18
18
18
18
Appendix C. Modbus Map
Read Only/
Read Write Format
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
117
