GE PanaFlow HT User Manual page 121

Appendix C. Modbus Map
Register Register (in
(in Hex) Decimal)
8608 34312
860A 34314
860C 34316
860E 34318
8610 34320
8612 34322
8614 34324
8616 34326
8618 34328
861A 34330
861C 34332
Channel 1 Integer - FF Terminal Block 4
8700 34560
8702 34562
8704 34564
8706 34566
8708 34568
870A 34570
870C 34572
Channel 2 Real - FF Terminal Block 5
8A00 35328
8A02 35330
8A04 35332
8A06 35334
8A08 35336
8A0A 35338
8A0C 35340
8A0E 35342
8A10 35344
8A12 35346
8A14 35348
8A16 35350
8A18 35352
8A1A 35354
8A1C 35356
Channel 2 Integer - FF Terminal Block 5
8B00 35584
8B02 35586
112
Table 10: XMIT Modbus Map (cont.)
Access
Level
VIEWER Ch_1 DeltaT
VIEWER Ch_1 Time in buffer on Dn channel
VIEWER Ch_1 Up Signal Quality
VIEWER Ch_1 Dn Signal Quality
VIEWER Ch_1 Up Amp Disc
VIEWER Ch_1 Dn Amp Disc
VIEWER Ch_1 Signal Gain Up
VIEWER Ch_1 Signal Gain Down
VIEWER Ch_1_SNR on UP channel
VIEWER Ch_1_SNR on DOWN channel
VIEWER Ch_1 Time in buffer on Up channel
VIEWER Ch_1 status bit map
VIEWER Ch_1 most significant error (see Error
Tables)
VIEWER Ch_1 Up +- Peak
VIEWER Ch_1 Dn +- Peak
VIEWER Ch_1 dynamic threshold on UP channel 12
VIEWER Ch_1 dynamic threshold on DOWN
channel
VIEWER Ch_1 #Errors of Last 16
VIEWER Ch_2 Velocity
VIEWER Ch_2 Sound Speed
VIEWER Ch_2 Transit Time Up
VIEWER Ch_2 Transit Time Dn
VIEWER Ch_2 DeltaT
VIEWER Ch_2 Time in buffer on Dn channel
VIEWER Ch_2 Up Signal Quality
VIEWER Ch_2 Dn Signal Quality
VIEWER Ch_2 Up Amp Disc
VIEWER Ch_2 Dn Amp Disc
VIEWER Ch_2 Signal Gain Up
VIEWER Ch_2 Signal Gain Down
VIEWER Ch_2_SNR on UP channel
VIEWER Ch_2_SNR on DOWN channel
VIEWER Ch_2 Time in buffer on Up channel
VIEWER Ch_2 status bit map
VIEWER Ch_2 most significant error (see Error
Tables)
Variable Unit Group
19
19
18
18
18
18
3
3
18
18
19
18
18
18
18
12
18
20
20
19
19
19
19
18
18
18
18
3
3
18
18
19
18
18
Read Only/
Read Write Format
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO INT32
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO (IEEE 32 bit)
RO INT32
RO INT32
