Input/Output Configuration on SM-DIN/Smart Matrix
This function allows you to configure the input/output signals of all the SM-DIN Boards
normally open (NO) or normally closed (NC) contacts. The parameters to be configured are distributed on 4
different windows (IN, OUT,
It also allows you to configure the output relay of SMART MATRIX terminal as normally open (NO) or
normally closed (NC) contact.
Input/Output Configuration on SM-DIN/Smart Matrix
CV%, PRX).
Enter the
Select
Select BOARDS.
Turn the selector to point in sequence each field of the
window
The frame indicates the "Pointed" field.
Click to select the pointed item. The field name will be
highlighted (reverse.
Example:
START
Turn the selector to choose the polarity of
(either Normally Open = NO, or Normally Closed = NC),
then click to confirm.
Point and select in sequence the
signals and set the relevant polarity.
Then point the window header (IN) and click to select it.
SMART MATRIX TWIST
SETUP
SETUP menu.
I/O CONFIG.
→ →
(IN START EXT 3
field selected (reverse)
→
I/O CONFIG
(BOARDS option) as
→ →
EXT 2 PRX).
START signal
EXT 3, EXT 2 and PRX
