Input/Output Configuration on
SM-DIN/Smart Matrix
This function allows you to configure the input/output signals of all the SM-DIN Boards
normally open (NO) or normally closed (NC) contacts.
It also allows you to configure the output relay
open (NO) or normally closed (NC) contact.
Input/Output Configuration on SM-DIN/Smart Matrix
(MATRIX
option) of SMART MATRIX terminal as normally
Enter the
SETUP
menu
Select
I/O
CONFIG.
Select BOARDS.
Configure the input signals
IN
window and the output signals (STOP1, STOP2) within
the
OUT
window, as
To activate the save function.
SAVE
to save the choice,
screen without saving,
SMART MATRIX MTC
SETUP
→
(BOARDS
(IN
1,
IN
2,
IN
3,
NO
or NC.
BACK
to return to the previous
EXIT
to return to menu.
I/O CONFIG
option) as
IN
4) within the
2 - 14
