Service Functions

This menu item allows you to carry out several service functions:
- Firmware upgrade on IS3.. sensors
- Reading the parameters programmed on sensors
- Reading the parameters programmed on SM-DIN Board
- Smart Matrix terminal function control
Sensors Firmware Upgrade
(SENS. UPG).
(SENS. READ).
(SMDIN
(CHK MASTER)
SETUP
Enter the SETUP
Select SERVICE.
Select SENS. UPG.
Select the sensor(s) for which you want to upgrade the
firmware.
In the "from" space you may choose the range of sensors
whose firmware shall be upgraded:
POSITION n to m
SECTION n to m
pointing and confirming the relevant fields.
In the "on side" space you may specify all machine sides
(ALL) or only the desired side
Examples:
to upgrade only the sensor No. 3 of side B, set:
from POSITION 3 to 3 on side B.
to upgrade all sensors of section 3, side A and B, set:
from SECTION 3 to 3 on side
Once you have selected the sensor(s) you want to
upgrade, press START.
SMART MATRIX TWIST
Service Functions
SETUP
READ).
→
SERVICE
menu.
or
(A or B).
ALL.
→
SERVICE
→
SENS. UPG
