ACT/POWER
The following figure shows the electrical interface (pin assignment) of ACT/POWER module.
ACT/POWER Technical Characteristics
Power supply voltage
Current absorption (sum of all 6 channels)
Max current absorbed by each channel
Operating temperature range
Storage temperature range
Overall dimensions
SMART MATRIX TWIST
Technical Characteristics
24 VDC
9A Max
1.5A Max
+10° / +60° C
-25° / +85° C
138.5x124x35 mm
- 1-11 -
