Note 1: The value increment/decrement resolution can be changed using the direct activation buttons B1,
B2, B3.
Setting example: ACQ.TIME:
Input/Output Configuration on SM-DIN/Smart Matrix
SAVE
to save the choice,
screen without saving,
No push button pressed: resolution x1
(increment/decrement by 1).
Resolution x10 (increment/decrement by 10).
Resolution x100 (increment/decrement by 100).
Resolution x1000 (increment/decrement by 1000).
SMART MATRIX TWIST
BACK
to return to the previous
EXIT
to return to menu.
- 2-16 -
