ETC ArcSystem Pro Multi-Cell RDM Installation Manual page 40

Parameter
DMX Start Address
DMX Personality
Identify Device
Minimum Level
Maximum Level
Curve
Curve Description
Output Response Time
Output Response Time
Down
Output Response Time
Description
Modulation Frequency
Modulation Frequency
Description
Restore Factory Defaults
Software Version Label
Bootloader Version Label
34
RDM PID Value
0x00F0 Range = 001 to 512
0x00E0 1 or 2
0 for stop identify, 1 for start
0x1000
identify
Minimum Level - Increasing: 0
to 255
0x0341
Minimum Level - Decreasing: 0
to 255
0x0342 0 to 255
0x0343 1, 2, or 3
0x0344
0x01 1000 ms/100 steps
0x0345
•
0x02 900 ms/90 steps
•
0x03 800 ms/80 steps
•
0x04 700 ms/70 steps
•
0x05 600 ms/60 steps
•
0x06 500 ms/50 steps
•
0x8030
0x07 400 ms/40 steps
•
0x08 300 ms/30 steps
•
0x09 250 ms/25 steps
•
0x0A 200 ms/20 steps
•
0x0B 100 ms/10 steps
•
0x0C 50 ms/5 steps
•
0x0D 0 ms/0 steps
•
0x0346
1 for 300 Hz
0x0347
•
2 for 600 Hz
•
3 for 1.2 kHz
•
4 for 19.2 kHz
•
0x0348
0x0090
0x00C0
0x00C2
Notes
Default is 001. The upper limit for multi-cell
luminaires is 512-N, where N is the number of
channels in the luminaire's personality. See
DMX Profile for the supported multiple-
channel configuration for each multi-cell
luminaire type.
Default is 2.See DMX Profile
multiple-channel configuration for each multi-
cell luminaire type.
Set to 1 sets DMX personality to multi-
•
channel.
Set to 2 sets DMX personality to single-
•
channel.
Set to 1 causes output(s) and LEDs of the unit
to blink in a one second on, one second off
pattern.
Default is 99%. The luminaire will not accept a
Minimum Level that is higher than the
Maximum Level.
Minimum Level - Increasing and Minimum
Level - Decreasing need to be set to the same
value.
Default is 100%. The luminaire will not accept a
Maximum Level that is lower than the Minimum
Level.
Set to 1 is the Default Tungsten Curve (aka
•
D04A)
Set to 2 is Linear
•
Set to 3 is Square Law
•
Get returns an ASCII text string.
Default is 500ms/50 steps. This parameter
controls dimming up in level.
Default is 500 ms/50 steps. This parameter
controls dimming down in level. Set 0x00 to set
the Output Response Time Down to the same
setting as Output Response Time.
Get returns an ASCII text string.
Default is 300 Hz.
Get returns an ASCII text string.
Set resets the luminaire configuration to
default settings.
Get returns the current software version as an
ASCII text string.
Get returns the current bootloader version as
an ASCII text string.
ArcSystem Pro Multi-Cell Installation Guide
