ETC Installation Guide
ArcSystem Pro One-Cell
Introduction
Congratulations on your purchase of ArcSystem products. ArcSystem is a family of overhead LED
products designed for installations where dimming, light quality, and ease of installation are
absolutely essential. With ArcSystem, you will experience perfectly smooth dimming from 100%
down to absolute zero. ArcSystem luminaires come in a variety of form factors, beam angles, and
color-temperature options, all with high-efficiency optics and an outstanding quality of light ideal for
any application.
ArcSystem products with ArcMesh can be controlled using wired DMX or the wireless ArcMesh
protocol. ArcSystem products without ArcMesh can be configured for RDM control. This manual
provides step by step instruction on the installation of ArcSystem products as well as full system
integration. For information on installing the ArcSystem TX1 Transmitter for use with ArcMesh
installations, see the ArcSystem Installation Manual at etcconnect.com/ArcSystem. All ETC manuals
are available for download free of charge at etcconnect.com.
Safety
ArcSystem products are intended for professional use only. Read the entire manual before using this
equipment.
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including
the following:
READ AND FOLLOW ALL SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Corporate Headquarters Middleton, WI, USA +1 608 831 4116 London, UK +44 (0)20 8896 1000
Holzkirchen, DE +49 (80 24) 47 00-0 Rome, IT +39 (06) 32 111 683 Hong Kong +852 2799 1220 Paris, FR +33 1 4243 3535
Web
© 2020 ETC, Inc. Trademark and patent
Product information and specifications subject to change. ETC intends this document to be provided in its entirety.
7491M2110 Rev D Released 2020-01
Do not use outdoors.
•
Do not let power supply cords touch hot surfaces.
•
Do not mount near gas or electric heaters.
•
Equipment should be mounted in locations and at heights where it will not readily
•
be subjected to tampering by unauthorized personnel.
The use of accessory equipment not recommended by the manufacturer may cause
•
an unsafe condition.
Do not use this equipment for other than intended use.
•
etcconnect.com
Support
support.etcconnect.com
Contact
etcconnect.com/contactETC
info: etcconnect.com/ip
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ETC ArcSystem Pro One-Cell Series
Summary of Contents for ETC ArcSystem Pro One-Cell Series
- Page 1 Holzkirchen, DE +49 (80 24) 47 00-0 Rome, IT +39 (06) 32 111 683 Hong Kong +852 2799 1220 Paris, FR +33 1 4243 3535 etcconnect.com Support support.etcconnect.com Contact etcconnect.com/contactETC © 2020 ETC, Inc. Trademark and patent info: etcconnect.com/ip Product information and specifications subject to change. ETC intends this document to be provided in its entirety. 7491M2110 Rev D Released 2020-01...
-
Page 2: System Overview
The ArcSystem Pro One-Cell High Output is not available in 3500 K, 4000 K, 5000 K, or Fade to Warm variants. ArcSystem Pro Multi-Cell luminaires are covered in the ArcSystem Pro Multi-Cell Installation Guide and ArcSystem Installation Manual . All ETC manuals are available for download free of charge at etcconnect.com. Pro One-Cell... - Page 3 ETC Installation Guide Pro One-Cell D1 Series, D2 Series, and D4 Series Drivers D1 Driver D1 HO Driver D2 Driver D4 Driver Note: Antenna is not present on RDM models. ArcSystem Pro One-Cell luminaires require an external driver. ArcSystem D1, D2, and D4 Series drivers use standard RJ45 connectors for DMX control.
- Page 4 Cell and One-Cell Small luminaires require a D1 driver or D4 driver to function. Note: All ArcSystem wireless luminaires require a TX1 Transmitter and commissioning tool to set DMX addresses for both wired DMX and wireless installations. Contact your ETC Service Technician for more information. Emergency System Overview ArcSystem drivers and luminaires can be purchased in UL924 listed variants.
- Page 5 ETC Installation Guide Pro One-Cell Emergency drivers and luminaires require two branch circuit connections. These inputs have the following functions: Normal branch circuit to sense failure of the normal supply. Connect to Sense Input connector. Normal/Emergency branch circuit providing power to the luminaire in both conditions.
-
Page 6: Before You Begin Installation
ETC Installation Guide Pro One-Cell Before You Begin Installation Review the following sections before beginning your ArcSystem installation. ArcSystem products should only be installed by a qualified installer or electrician. Power Disconnect Device Before installation, make sure you have a readily accessible input power disconnect device installed ahead of your ArcSystem products. -
Page 7: Preparing To Install The Driver
DMX. The following illustration shows an example of a linear ceiling installation with one luminaire for each D1 Series driver. The cable between an ArcSystem Pro One-Cell Series luminaire and its driver is approximately 1 m (40 in) long. Note: If you want to daisy chain power wiring, it must be connected through a junction box as shown below. - Page 8 Install the driver on a power distribution system with reliably identified earthed neutral (ground) and install a maximum 20 A circuit breaker on the line conductor. The D1, D2, and D4 Series drivers accept 100–277 VAC, 50/60 Hz. ETC recommends installing all wiring in grounded metal conduit. WARNING: Circuits that are installed without an accessible power disconnect device cannot be serviced or operated safely.
- Page 9 Depending on your installation, you might want to surface-mount the driver. Any ArcSystem standalone driver can be surface-mounted to any surface capable of supporting its weight using the four holes located on the back side of the enclosure. Contact ETC for custom mounting bracket options.
- Page 10 ETC Installation Guide Pro One-Cell Note: Make sure that the flexible electrical supply can extend through the ceiling opening so that the driver and luminaire can be inspected and serviced when needed. Note: Use suitable conduit where required by national and local codes.
- Page 11 ETC Installation Guide Pro One-Cell Preparing the Ceiling for Recessed Luminaires This section is specific to the recessed/flush mounted variant of luminaires. For Pro One-Cell yoke- Wiring the Driver and Luminaire on page 12 mounted luminaires, proceed to Cut a hole in the ceiling or ceiling tile to accommodate the luminaire’s retaining clip anchors. Cut the hole larger than the minimum hole diameter listed below and smaller than the luminaire’s outer...
- Page 12 ETC Installation Guide Pro One-Cell Wiring the Driver and Luminaire Wiring of the driver consists of wiring power and data (DMX) to the driver for your luminaire and then running power out to the luminaire from the driver. If you are installing emergency system drivers, see Emergency System One-Cell Installation on page 19...
- Page 13 ETC Installation Guide Pro One-Cell LED4 LED3 Switch Output type blocks varies by model LED2 LED1 D4 Driver Constant Current with Molex connectors Constant Current with terminal outputs Constant Voltage with terminal outputs Pro One-Cell Page 13 of 29...
- Page 14 ETC Installation Guide Pro One-Cell Power Internal wire colors vary by model. Factory Wire Colors Model Color Type North America ground/earth green/yellow and Europe North America black line/hot North America white neutral Europe brown live Europe blue neutral Perform the following steps to wire power to the driver.
- Page 15 ETC Installation Guide Pro One-Cell Luminaire Connection to Driver ArcSystem Pro One-Cell luminaires connect to a driver using Molex receptacles labeled "LED Head" for D1 and D2 Series Drivers and "LED" followed by output channel number for D4 Series drivers. All D1 Series and D2 Series drivers and some models of D4 Series drivers have Molex receptacles for ArcSystem Pro One-Cell luminaire connections.
- Page 16 ArcSystem multi-cell luminaires and standalone drivers are not self-terminating. You must terminate the last multi-cell luminaire or standalone driver in line with a 120 Ω resistor. To purchase an RJ45 terminator, please contact your ETC customer service representative and request part number N4086. Pro One-Cell...
-
Page 17: Switch Functions
Switches 2 through 5 are factory set to allow each output to be controlled by an individual DMX address. ETC recommends leaving the DMX channel switches (positions 2 through 5) at their factory settings and using the ArcSystem Configuration Software or RDM settings to control the behavior of each output. - Page 18 ETC Installation Guide Pro One-Cell Installing One-Cell Recessed Luminaires The installation procedure is similar for all recessed one-cell luminaires (fixed and adjustable). For Installing One-Cell Yoke-Mounted Pro One-Cell yoke-mounted luminaires, continue on to Luminaires below WARNING: ArcSystem Pro One-Cell, One-Cell Small, and One-Cell High...
- Page 19 ETC Installation Guide Pro One-Cell Emergency System One-Cell Installation With the exception of power input terminations, ArcSystem emergency system installation requirements are the same as those of the standard ArcSystem. Complete the installation as follows, referencing the following sections for any additional installation details before wiring the power: Preparing to Install the Driver on page 7...
- Page 20 ETC Installation Guide Pro One-Cell LED4 LED3 Switch Output type blocks varies by model LED2 LED1 SENSE SENSE D4 Emergency Driver Constant Current with Molex connectors Constant Current with terminal outputs Constant Voltage with terminal outputs Pro One-Cell Page 20 of 29...
- Page 21 ETC Installation Guide Pro One-Cell Note: If you are installing a D1 High Output driver, the power supply is inside the cover and has wiring that runs to the driver board in the back panel of the driver. Be careful when handling.
-
Page 22: Complete Installation
Switches 2 through 5 are factory set to allow each output to be controlled by an individual DMX address. ETC recommends leaving the DMX channel switches (positions 2 through 5) at their factory settings and using the ArcSystem Configuration Software or RDM settings to control the behavior of each output. -
Page 23: Final Installation
DMX, or a hybrid of the two, making it a great solution for both new construction and retrofit situations. ArcSystem RDM Systems can be controlled over wired DMX from a lighting console or ETC Concert software. Concert is available for free download at etcconnect.com/Concert. - Page 24 ETC Installation Guide Pro One-Cell ArcSystem wireless luminaires ARC-TX1 DMX512 DMX512 DMX512 from lighting console ArcSystem wired DMX luminaires Third party DMX devices Note: By default the TX1 DMX output is disabled. If you require DMX output from the TX1, you must use the ArcSystem comissioning tool software to add DMX fixtures.
- Page 25 Get returns the current bootloader version as an ASCII text string. Updating the Luminaire Software ETC recommends using UpdaterAtor software to manage software updates. For more information on UpdaterAtor, download the UpdaterAtor Software Quick Guide for free from etcconnect.com. Pro One-Cell Page 25 of 29...
-
Page 26: Maintenance
ETC Installation Guide Pro One-Cell Maintenance WARNING: RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all power to the system before installation, maintenance, cleaning, or any other system modification could result in serious injury or death. AVERTISSEMENT : RISQUE DE MORT PAR DÉCHARGE ÉLECTRIQUE! Négliger de débrancher toutes les sources d’alimentation du système avant l’installation,... - Page 27 ETC Installation Guide Pro One-Cell Emergency Operation and Test It is important to test ArcSystem emergency systems regularly because they are life safety devices. NOT SELF-TESTING PER ANSI/NFPA 101 - This equipment is not self-testing in conformance with the Life Safety Code, ANSI/NFPA 101. ANSI/NFPA 101 Life Safety Code requires testing of life safety devices every 30 days.
- Page 28 ETC Installation Guide Pro One-Cell Compliance ArcSystem One-Cell Luminaires Model Description Compliance cULus ARCP1 ArcSystem Pro One-Cell Conforms to UL 2108 • Conforms to UL 924 • Conforms to UL 2043 plenum • rating (ARCP1, ARCP1S, and ARCP1S ArcSystem Pro One-Cell Small ARCP1H, recessed variants only) Certified to CSA C22.2 No.
-
Page 29: Fcc Compliance
ETC Installation Guide Pro One-Cell ArcSystem D1, D1HO, D2, and D4 Emergency Drivers Model Description Compliance ARCPED1DM* ArcSystem D1 Emergency Driver ARCPED1DRDMM ArcSystem D1 RDM Emergency Driver ARCPED1HDM* ArcSystem D1 High Output Emergency Driver ARCPED1HDRDMM ArcSystem D1 High Output RDM Emergency Driver...
