Terminate Building Wiring to the Canopy

See Emergency System Overview on page 5
Maintained (normal/emergency) feeds.
A DMX In
B DMX Thru
Emergency/maintained power
C
line/hot (black)
Emergency/maintained power
D
common (white)
E Ground (green/yellow)
F Normal/sense line/hot (black)
G Normal/sense common (white)
Terminate Power
Connect maintained/emergency power
to the Maintained Input on the canopy
as instructed in
page 18 .
Connect normal/sense power to the
sense input on the canopy.
Electrical and Wiring
1. See
Specification on page 10
specification of wire and strip length.
Prepare wires accordingly.
2. Terminate ground.
a. Locate the WAGO connector on
the ground wire (green, E in the
illustration at
277 V Emergency Four-Cell
Pendant on page 27
b. Run a ground wire (typically
green/yellow) through conduit,
into the junction box, and to a
free position on the
WAGO connector.
c. Lift up the orange clip, insert the ground wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
3. Terminate neutral.
a. Locate the WAGO connector on the neutral wire (white, D in the illustration
Installing a 100–277 V Emergency Four-Cell Pendant on page 27
at
b. Run a neutral wire (typically white or gray) through conduit, into the junction box, and
to a free position on the WAGO connector.
c. Lift up the orange clip, insert the neutral wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
Installing 100–277 V Emergency Multi-Cell Luminaires
Terminate Power on
for
Installing a 100–
.
for an explanation of Sense (normal) and
A A DMX IN DMX THRU
G
F
E
Factory Wire Colors
Model
North America
North America
North America
Europe
Europe
Europe
C
B B
D
Color Type
green/yellow ground
black line/hot
white common
green/yellow earth
brown live
blue neutral
).
29
