Emergency System Overview

ArcSystem drivers and luminaires can be purchased in UL924 listed variants. Each of the

luminaires can be configured to be UL924 listed when wired into an existing emergency

response system. See

Emergency Multi-Cell Luminaires

Install the ArcSystem multi-cell luminaire in a location that is accessible by qualified personnel

for testing of the emergency operation.

Note:

for UL924 certification.

Note:

responsibility of the specifier and installer in order to achieve the minimum FC levels of

NFPA101. Installation scenarios should be evaluated by the AHJ to confirm illuminance

and performance requirements of ANSI/NFPA 101 and the IBC.

Note:

installed with a maximum mounting height of 23.2 ft (7.07 m).

Note:

according to NEC 700.10(B).

System Overview

Installing Four-Cell Round Emergency Luminaires

Luminaires must be hard-wired to emergency certified drivers to be considered

The number of designated emergency lamps and their height is the

ArcSystem Pro One-Cell Micro luminaires in emergency installations must be

Installation must follow all national and local codes for electrical equipment.

Normal and emergency wiring cannot be contained in the same conduit

and

Installing 100–277 V
