Connect the Power Input

1. See Wire and Terminal Specifications on page 10
Prepare wires accordingly.
2. Remove the three screws securing the wiring compartment cover to the luminaire. The
cover is grounded by a tether to the enclosure. Set the screws aside.
3. Terminate ground.
a. Locate the WAGO connector on the ground wire (green) connected to the bottom of
the wiring compartment (
b. Run a ground wire (typically green/yellow) through conduit to a free position on the
WAGO connector.
c. Lift up the orange clip, insert the ground wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
4. Terminate neutral.
a. Locate the WAGO connector on the neutral wire (white) from the input.
b. Run a neutral wire (typically white or grey) through conduit to a free position on the
WAGO connector.
c. Lift up the orange clip, insert the neutral wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.
5. Terminate line (hot).
a. Locate the WAGO connector on the line (hot) wire (black) from the input.
b. Run a line (hot) wire through conduit to a free position on the WAGO connector.
Note:
brown, orange, or yellow.
c. Lift up the orange clip, insert the line wire, and press the clip down onto the wire.
d. Tug gently to make sure the wire is secure.

Terminate DMX

DMX In and DMX Thru cables terminate to RJ45 connectors.
DMX is installed in a daisy chain topology and includes one pair
of wires (data +, data -) plus an ISO ground (common). ETC
recommends Cat5e (or better) minimum 24 AWG conductors
terminated to T568B standard. Up to 32 luminaires can be
connected per DMX run.
1. If using hard wired DMX, plug the RJ45 connector into the
DMX in port on the rear of the luminaire.
2. If linking additional luminaires via DMX, plug a RJ45 cable into the DMX thru port on the
rear of the luminaire.
Note:
and Pro Eight-Cell luminaires are not self-terminating. You must terminate the last
luminaire in line with a 120 Ω resistor. To purchase an RJ45 terminator, please contact
your ETC customer service representative and request part number N4086.
ArcSystem 100–277V Pro Four-Cell Pendant luminaires have a DMX termination switch
(see Canopy DMX In and Thru on
Installing 100–277 V Multi-Cell Luminaires
Line (hot) wire color varies based on voltage and region but is typically black,
ArcSystem 100–277 V Pro Two-Cell, Pro Four-Cell Square, Pro Four-Cell Linear,
for specification of wire and strip length.
).
page 21).
RJ45 Pinout Information
Pin Description
1 Data +
2 Data -
ISO ground
7&8
(common)
