Canopy Low-Voltage Power
The low-voltage power wiring consists of red and black wires that have pre-stripped ends.
Connect the red and black wires to the WAGO connectors that are wired to the power supply (F
and G in the illustration at
1.
2.
Note:
pair with a two-pin plug for emergency/sense. Do not connect the
emergency/sense twisted wire pair to the WAGOs inside the canopy. See
Installing a 100–277 V Emergency Four-Cell Pendant on page 27
information on installing a Pro Four-Cell Emergency Pendant.

Complete Canopy Installation

1. Slide canopy cover up to the top of the stem.
2. Reconnect the canopy cover grounding harness (A in the illustration at
Inside the Canopy on page 20
a. Use a 7 mm nut driver and the nut removed in Step 2 of
page 16
the canopy cover.
3. Fit the canopy cover to the canopy, ensuring that wires are not pinched in the canopy stem
slot or the around the perimeter of the canopy cover.
4. Install canopy cover with two M4x8 mm Phillips screws (item 3 in the illustration at
277 V Four-Cell Pendant Components on page 15
22
Terminate Wiring Inside the Canopy on page 20
Insert the red (+) wire into the empty terminal on the WAGO with the red wire.
Insert the black (-) wire into the empty terminal on the WAGO with the black
wire.
Pro Four-Cell Emergency Pendants have a red and black twisted wire
to secure the canopy cover grounding harness onto the ground stud inside
).
).
).
for more
Terminate Wiring
Remove the Canopy Cover on
