ETC ArcSystem Pro Multi-Cell RDM Installation Manual page 25

5. Insert the buliding line wire (hot) into a terminal on the WAGO with the black wire on the
canopy (C in the illustration at
page ).
Note:
black, brown, orange, or yellow.
DMX In and Thru
Note:
the stem length to DMX run length calculations for each Four-Cell Pendant in a
DMX run. DMX In wiring runs from the canopy of the Four-Cell Pendant through the
stem to the fixture body, and DMX Thru wiring runs from the fixture body through the
stem to the canopy.
DMX connections may use either Belden 9729 or Cat5 (or equivalents). Screw-terminal
connectors are provided for use with Belden 9729. IDC connectors are provided for use with
Cat5 (or equivalent). Cable preparation instructions for DMX termination are contained in the
setup guides that are included in the termination kit, and are also available for free download at
etcconnect.com.
1. Terminate DMX/RDM input from the control source, through the back box, to the canopy
mounting plate.
a. If using Belden 9729:
a.
b.
If using Category 5:
a.
b.
2. Optionally, terminate DMX/RDM thru to the next device in the DMX data run. Up to 32
DMX/RDM devices can be daisy-chained together per data run.
a. See the specific termination setup guide for the type of cable used in the installation,
either Belden 9729 or Cat5.
b. Install the connector with wires terminated to the "DMX Thru" receptacle on the
termination board.
3. Terminate DMX/RDM data signal for the last DMX/RDM device in the data run by setting
the termination switch on the termination board to "ON". All other devices in the data run
maintain the factory default termination switch setting: "OFF". See
Thru on page 21
Installing 100–277 V Multi-Cell Luminaires
Building wire color varies based on voltage and region, but line (hot) is typically
Stem length will impact total length calculations for DMX runs. Add two times
See the DMX Cable Preparation for Screw Termination Setup Guide for
instructions to prepare and terminate Belden 9729 for DMX/RDM input cable to
the screw terminal connector.
Install the screw terminal connector with wires terminated to the "DMX In"
receptacle on the termination board.
See the Cat5 Cable Preparation for IDC Termination Setup Guide for instructions
to prepare and terminate Category 5 for DMX/RDM input cable to the insulation
displacement connector.
Install the IDC connector with wires terminated to the "DMX In" receptacle on
the termination board
Terminate Building Wiring to the Canopy on the previous
Canopy DMX In and
19
