Updating the Luminaire Software

When commissioning a system installation, check all ArcSystem drivers and multi-cell luminaires
to ensure that the latest firmware is present. If the firmware is not up to date, upgrade it using
ETC Concert and ETC UpdaterAtor software before commissioning is completed. For more
information on UpdaterAtor, download the UpdaterAtor Software Quick Guide for free from
etcconnect.com.

Multi-Cell Luminaire LEDs

ArcSystem multi-cell luminaires have DMX LEDs that indicate the status of the processor and
DMX communication.

DMX Link LED

Slow flash: normal operation. DMX broadcast is being received and DMX data is not
•
changing.
Solid On: active DMX signal is being received
•
Solid On: DMX is present
•

DMX Status LED

Steady blinking: processor is operating normally
•
Solid On: system is responding to DMX instruction
•
Solid On when no DMX command is being sent: there is a processor fault. Contact ETC
•
Technical Services for assistance.

Maintenance

WARNING:
power to the system before installation, maintenance, cleaning, or any
other system modification could result in serious injury or death.
AVERTISSEMENT :
Négliger de débrancher toutes les sources d'alimentation du système avant
l'installation, l'entretien, le nettoyage ou toute autre modification du
système peut causer des blessures graves ou la mort.
De-energize main feed to ArcSystem and follow appropriate Lockout/Tagout
procedures as mandated by NFPA 70E. It is important to note that electrical
equipment such as breaker panels can present an arc flash hazard if
improperly serviced. This is due to the high amounts of short-circuit current
available on the electrical supply to this equipment. Any work must comply
with OSHA Safe Working Practices.
WARNING:
cool before performing any cleaning and maintenance.
AVERTISSEMENT :
et la laisser refroidir avant d'effectuer un nettoyage ou un entretien.
WARNING:
disconnect device cannot be serviced or operated safely.
AVERTISSEMENT :
installés sans qu'un dispositif de déconnexion de l'alimentation ne soit
accessible.
Final Installation and Operation
RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all
RISQUE DE MORT PAR DÉCHARGE ÉLECTRIQUE!
Disconnect the fixture from power and DMX and allow it to
Débrancher la lampe de son alimentation et du DMX
Circuits that are installed without an accessible power
Il est imprudent d'utiliser ou de réparer les circuits
