Installing 100–240 V Multi-Cell Luminaires
100–240 V multi-cell yoke mounted luminaires include the Pro Two-Cell, Pro Four-Cell Linear,
Pro Four-Cell Square, and Pro Eight-Cell. For 100–240 V Pro Four-Cell Round, see
240 V Four-Cell Round Luminaires on the facing page
100–277 V Multi-Cell Luminaires on page 10
Note:
luminaire.
DMX
DMX In and DMX Thru cables terminate to RJ45 connectors. DMX is installed in a daisy chain
topology and includes one pair of wires (Data +, Data -) plus an ISO ground (common). ETC
recommends Cat5e (or better) minimum 0.2 mm
standard. Up to 32 multi-cell luminaires can be connected per DMX run.
RJ45 Pinout Information
Pin
Description
1
Data +
2
Data -
ISO ground
7&8
(common)
Installation Procedure
1.
Attach a C-clamp or other mounting hardware (not provided) to the yoke of the luminaire.
2.
Attach the luminaire to a pipe or other approved mounting device.
3.
Insert or attach additional accessories, if desired.
4.
Connect the provided power cable.
5.
If using hard-wired DMX, plug the RJ45 connector into the DMX in port on the rear of the
luminaire.
6.
If linking additional luminaires via DMX, plug an RJ45 cable into the DMX thru port on the
rear of the luminaire.
Note:
luminaire in line with a 120 Ω resistor.
To purchase an RJ45 terminator, please contact your ETC customer service
representative and request part number N4086.
7.
Toggle the power switch to "ON."
8.
Rotate the luminaire so it is roughly focused to its final resting position. This will assist in
final focus procedures.
8
Mounting hardware and installation location must support the weight of the
ArcSystem luminaires are not self-terminating. You must terminate the last
. For 100–277 V luminaires, see
.
2
(24 AWG) conductors terminated to T568B
DMX In and Thru
connections
Power switch
Power connection
ArcSystem Pro Multi-Cell Installation Guide
Installing 100–
Installing
Four-cell square
luminaire shown
