4.
Terminate line (hot).
a.
Locate the WAGO connector on the line (hot) wire (black, C in the illustration at
Installing a 100–277 V Emergency Four-Cell Pendant on page 27
b.
Run a line (hot) wire through conduit, into the junction box, and to a free position on
the WAGO connector.
c.
Lift up the orange clip, insert the line (hot) wire, and press the clip down onto the
wire.
d.
Tug tently to make sure the wire is secure.
Note:
black, brown, orange, or yellow.
DMX In and Thru
Terminate DMX In and Thru as instructed in
Install the Canopy Mounting Plate to the Back Box
Install the canopy mounting plate to the back box as instructed in
Plate on the Back Box on page 20
Hang the Stem in the Canopy
Connect the stem to the canopy as instructed in
Terminate Wiring Inside the Canopy
Canopy cover grounding
A
harness (green/yellow)
Cylinder grounding harness
B
(green/yellow)
Stem grounding harness
C
(green/yellow)
D Eight-terminal DMX plug
E DMX termination switch
Low-voltage maintained power
F
- (black)
Low-voltage maintained power
G
+ (red)
Low-voltage sense feed (red
H
and black)
1.
Terminate ground as instructed in
2.
Terminate low-voltage maintained power as instructed in
page 22
3.
Terminate DMX In and Thru as instructed in
Note:
by setting the yellow termination switch on the termination board (E in the illustration)
to ON. All other devices in the data run maintain the factory default termination switch
setting OFF.
4.
Terminate the red and black sense feed harness to the sense board (H in the illustration
above).
30
Building wire color varies based on voltage and region, but line (hot) is typically
.
E
F
G
.
Terminate DMX/RDM data signal for the last DMX/RDM device in the data run
DMX In and Thru on page 19
Hang the Stem in the Canopy on page 20
D
Ground on page 21
.
Canopy DMX In and Thru on page 21
ArcSystem Pro Multi-Cell Installation Guide
).
.
Install the Canopy Mounting
C
B
H
Canopy Low-Voltage Power on
.
A
.
