Installing 100–277 V Multi-Cell Luminaires
This section provides the information needed to install 100-277 V Multi-Cell luminaires. For
instructions on installing 100–277 V pendant fixtures, see
Pendant on page 14

Supplies

The following supplies are required for installation, but not provided:
½ in flex conduit and conduit fittings
•
Appropriate strain relief connectors for the installation type, as needed
•
Phillips screwdriver
•
120Ω RJ45 terminator for DMX termination. See
•
Wire stripping and cutting tool
•
Note:
luminaire, conduit hardware, and all cable required for installation.

Electrical and Wiring Specification

Install ArcSystem 100–277 V luminaire on a power distribution system with reliably identified
earthed neutral and install a maximum 20 A circuit breaker on the line conductor.
ArcSystem 100–277 V luminaires and drivers accept 100–277 VAC, 50/60 Hz. ETC recommends
installing all wiring in grounded metal conduit.
Wire and Terminal Specifications
Luminaire Type
Two-Cell,
Four-Cell Square,
Four-Cell Linear,
Eight-Cell
Four-Cell Pendant
Note:
and Pro Eight-Cell luminaires are not self-terminating. You must terminate the last
luminaire in line with a 120 Ω resistor. To purchase an RJ45 terminator, please contact
your ETC customer service representative and request part number N4086.
ArcSystem 100–277V Pro Four-Cell Pendant luminaires have a DMX termination switch
(see Canopy DMX In and Thru on
10
.
Mounting hardware and installation location must support the weight of the
Terminal / Conduit
Connector Entry
Power Input -
½ in conduit
line/neutral/ground
DMX In/Thru
N/A
RJ45 Connectors
Power Input -
N/A
line/neutral/ground
DMX In/Thru N/A
ArcSystem 100–277 V Pro Two-Cell, Pro Four-Cell Square, Pro Four-Cell Linear,
Installing a 100-277 V Four-Cell
Terminate DMX on page 13
Wire Range / Specification
0.2–4 mm
(24–12 AWG)
Cat5e (or better) minimum 0.2 mm
terminated to T568B standard
0.2–4 mm
(24–12 AWG)
Belden 9729 (or equivalent) or Cat5e (or better) minimum
2
0.2 mm (24 AWG) conductors terminated to T568B standard
page 21).
.
Strip Length
11 mm (0.43 in)
2
(24 AWG) conductors
11 mm (0.43 in)
