Terminate Power Wiring

ArcSystem 100–277 V systems are supplied with WAGO
for convenient power connections in normal and emergency luminaires. Non-emergency
ArcSystem 100–277 V systems are supplied with three two-position WAGO connectors (ETC part
number J4717, WAGO part number 221-412). See
Luminaires on page 24
Factory Wire Colors
Model Color
North America green/yellow
North America black
North America white
Europe green/yellow
Europe brown
Europe blue
Detail of two-cell luminaire or four-cell square
luminaire wiring compartment
Note:
12
for more information about wiring for emergency installations.
Type
ground
line/hot
common
earth
live
neutral
Building wire colors may be different than shown.
®
connectors in the wiring compartment
Installing 100–277 V Emergency Multi-Cell
Detail of eight-cell luminaire
wiring compartment
Detail of
four-cell linear
luminaire wiring
compartment
