System Overview

ArcSystem luminaires are available in 100–240 V standard models with IEC connectors, 100–
125 V emergency models with NEMA 5-15 connectors, or 100–277 V hard-wired standard or
emergency models. ArcSystem Pro One-Cell luminaires require an external driver.
Models are available to meet your installation requirements. This guide covers the products
listed below.
ArcSystem Pro Two-Cell
integral driver
•
ideal for medium throw
•
55 W full load power consumption
•
Standard: 100–240 V with IEC connector
•
or 100–277 V hard-wired input options
Emergency: 100–277 V hard-wired input
•
options
yoke-mount only
•
beam angle options: 19°, 24°, 37°, 60°
•
ArcSystem Pro Eight-Cell
integral driver
•
ideal for long throw
•
200 W full load power consumption
•
Standard: 100–277 V hard-wired input
•
options
Emergency: 100–125 V with NEMA 5-15
•
connectors or 100–277 V hard-wired
input options
yoke-mount only
•
beam angle options: 19°, 24°, 37°, 60°
•
Note:
wired input. The ArcSystem Pro Four-Cell Round is only available with 100-240 V input
with IEC connectors (standard models) or 100–125 V input with NEMA 5-15 connectors
(emergency models).
ArcSystem Pro One-Cell luminaires are covered in the ArcSystem Pro D1 and D2 Series Drivers
Installation Guide , ArcSystem Pro D4 Series Drivers Installation Guide , and ArcSystem Pro
Installation Manual . All ETC manuals are available for download free of charge at
etcconnect.com.
4
The ArcSystem Pro Four-Cell Pendant is only available with 100–277 V hard-
ArcSystem Pro Four-Cell
integral driver
•
ideal for medium/long throw
•
100 W full load power consumption
•
Standard: 100–240 V with IEC connector or
•
100–277 V hard-wired input options
Emergency: 100–277 V hard-wired input
•
options (linear, square, and pendant); 100–125
V hard-wired cables with NEMA 5-15
connectors (four-cell round, North America
only); 100–240 V hard-wired cables with bare
ends (four-cell round, Europe)
linear and square yoke-mount, round, and
•
pendant options
beam angle options: 19°, 24°, 37°, 60°
•
standard pendant stem lengths are 6, 12, 24,
•
36, 48, 72, and 96 inches
custom pendant stem lengths can be ordered
•
pendant accommodates up to 34° sloped
•
ceiling
