Following their respective calibration, the Grippers will display their actual stroke, from the fully closed to the fully open position.
Features
Icon
Fig. 4-5: Second step of the calibration wizard
Fig. 4-6: Single Gripper, calibrated
Functionality Name
Calibration
Calibrate/Recalibrate
Robotiq CN C M achine Tending Kit Instruction M anual
Description
After selecting the Gripper in the left pane
of the Installation tab, tap this button to
access the Gripper Calibration menu.
The Calibrate and Recalibrate buttons
launch the Gripper Calibration wizard.
