8.1 .2. Dimensions of the Wrist Camera
Fig. 8-5: Hardware of the Wrist Camera.
Fig. 8-6: Dimensions and weight of the Wrist Camera.
Specification
Maximum load
Weight (without tool plate)
Weight (with tool plate)
Added height (without tool plate, for
use with 2-Finger Gripper)
Global thickness (without tool plate)
Added height (with tool plate)
Global thickness (with tool plate)
Robotiq CN C M achine Tending Kit Instruction M anual
Value
1 0 kg
40 Nm
1 60 g
230 g
1 3.5 mm
22.4 mm
23.5 mm
29.5 mm
