Connecting Probes

The Vivid™ 3 ultrasound unit operates with various types of probes that are used for scanning patients,
including flat phased, convex and linear electronic array probes. Once connected, the probes can be
selected for different applications.
Probe connectors on the unit's control panel are as follows:
• Three active probe connectors (one for a pencil probe), and a fourth, inactive port on the right side
of the unit, which is used for parking.
OR
• Four active probe connectors (one for a pencil probe).
Probes can be connected or changed any time, as described below:
1) Inspect the probe socket to verify that it is free of debris.
2) Hold the rectangular probe connector vertically so that the probe's cable points upwards.
3) Rotate the probe locking latch counterclockwise to the unlock (horizontal) position.
4) Gently insert the connector into one of the matching sockets on the front of the unit. Gently push
the connector in as far as possible.
5) Rotate the locking latch 90 degrees clockwise to lock the connector into place (vertical).
NOTE: It is not necessary to turn OFF power to connect or disconnect a probe.
3-5-3-1 Available Probes
The following probes are available for use with the Vivid™ 3 ultrasound unit:
Table 3-15
2232337
2259135
2259145
2259153
2259206
2295377
2263669
2266328
2169773
2259246
KN100011
KN100022
KN100023
KN100072
KZ200476
TE100024
TQ100002
KZ200476
2301954
KQ100006
KW100011
3-28
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
7
EVISION
Available Probes
P/N
3S SECTOR (new design)
7L (546L)
10L (739L) LINEAR
C358 PROBE (OUTSIDE JAPAN)
I739L LINEAR
12L
7S SECTOR
10S
P509 (Japan)
T739L LINEAR
5T TEE MULTIPLANE
6T (Super TEE)
8T (Ped TEE)
9T(PED TEE) (for RFI systems only)
5S SECTOR
Pencil P2D
Pencil P6D
Adaptor PAMPTE/6Tv
E721
i8L
i13L
