7-2-3

Accessing the Diagnostic Menu

The diagnostic tools are accessed from 2D-Mode by simultaneously pressing <Ctrl+F11> on the
alphanumeric keyboard. The Diagnostic menu is displayed, as shown below:
Note: Once the test has been completed, a log can be viewed, as described in the
Interface
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
7
EVISION
Figure 7-1 Diagnostic Menu
section, on page 7-84.
Chapter 7 - Diagnostics/Troubleshooting
V ™ 3 P /V ™ 3 S
IVID RO IVID
Software Version
Option Buttons
Description Area
Report and Exit Buttons
Common Service
