GE Vivid 3 Pro Service Manual page 162

GE M S
EDICAL YSTEMS
D 2300164-100, R
IRECTION
4-4-4-3 CFM Stationary Noise Test
Table 4-35
Step
1
2
3
4
4-4-4-4 Probe Operation Check (Alignment & Sensitivity)
Table 4-36
Step
1
2
4-22
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
7
EVISION
CFM Stationary Noise Test (739L)
Task
Use the vertical nail area in the Electronic
Flow Phantom RMI1425A.
Place the 739L probe above the vertical nails
line (position 1).
Select a Cardiac preset and activate CFM.
Set the following CFM parameters:
• Gain: Max possible without color noise
• Tissue Priority: 0
• Flash: 0
Probe Operation Check (Alignment and Sensitivity) Test (739L)
Task
Use the Electronic Flow Phantom RMI1425A.
Set the Phantom settings as follows:
• Preset: 3
• Mode: Steady
Section 4-4 - Image Testing: 2D/M/CFM/Doppler
V ™ 3 P
IVID RO
Expected Result(s)
Ensure that the color does not appear constantly on the white nail.
Expected Result(s)
/V ™ 3 S M
IVID ERVICE ANUAL
