WEG CFW11W G2 Series User Manual page 88

Fault/Alarm
A191:
(3)
Temperature Alarm Sensor 1
A192:
(3)
Temperature Alarm Sensor 2
A193:
(3)
Temperature Alarm Sensor 3
A194:
(3)
Temperature Alarm Sensor 4
A195:
(3)
Temperature Alarm Sensor 5
A196:
(3)
Cable Sensor 1 Alarm
A197:
(3)
Cable Sensor 2 Alarm
A198:
(3)
Cable Sensor 3 Alarm
A199:
(3)
Cable Sensor 4 Alarm
A200:
(3)
Cable Sensor 5 Alarm
F228:
Serial Communication
Timeout
F229:
Anybus Offline
F230:
Anybus Access Error
F233:
Without CAN Supply
F234:
Bus Off
F235:
CANopen Communication
Error
F236:
Master in Idle
F237:
DeviceNet Connection
Timeout
F238:
(2)
Profibus Clear Mode
F239:
(2)
Profibus Offline
F240:
(2)
Profibus Interf. Access Error
Description
Temperature alarm in sensor 1.
Temperature alarm in sensor 2.
Temperature alarm in sensor 3.
Temperature alarm in sensor 4.
Temperature alarm in sensor 5.
Broken cable alarm in sensor 1.
Broken cable alarm in sensor 2.
Broken cable alarm in sensor 3.
Broken cable alarm in sensor 4.
Broken cable alarm in sensor 5.
Refer to the RS-232/RS-485 Serial communication manual.
Refer to the Anybus-CC communication manual.
Refer to the CANopen communication manual and/or refer to the DeviceNet communication manual.
Refer to the CANopen communication manual.
Refer to the DeviceNet communication manual.
It indicates that the inverter received the command
from the DP Profibus network master to go into
Clear mode.
It indicates interruption in the communication
between the DP Profibus network master and the
inverter.
It indicates error in the access to the data of the
Profibus DP communication module.
Troubleshooting and Maintenance
Possible Causes
High temperature on the motor.
„
Problem in the wiring that connects the IOE-01
„
Module (02 or 03) to the sensor.
High temperature on the motor.
„
Problem in the wiring that connects the IOE-01
„
Module (02 or 03) to the sensor.
High temperature on the motor.
„
Problem in the wiring that connects the IOE-01
„
Module (02 or 03) to the sensor.
High temperature on the motor.
„
Problem in the wiring that connects the IOE-01
„
Module (02 or 03) to the sensor.
High temperature on the motor.
„
Problem in the wiring that connects the IOE-01
„
Module (02 or 03) to the sensor.
Short circuited temperature sensor.
„
Short circuited temperature sensor.
„
Short circuited temperature sensor.
„
Short circuited temperature sensor.
„
Short circuited temperature sensor.
„
Check the network master status, ensuring it is
„
in the Run mode.
The fault indication will occur if P0313 = 5.
„
For further information, refer to the Profibus DP
„
communication manual.
Check if the network master is correctly
„
configured and operating properly.
Check the network installation in general –
„
cabling, grounding.
The fault indication will occur if P0313 = 5.
„
For further information, refer to the Profibus DP
„
communication manual.
Check if the DP Profibus Module is correctly
„
fitted in slot 3.
The fault indication will occur if P0313 = 5.
„
For further information, refer to the Profibus DP
„
communication manual.
