Chapter 1: VC7222 Board Features and Operation
Table 1-14:
30
Send Feedback
GTH Transceiver Reference Clock Inputs (Cont'd)
FPGA (U1) Pin
Net Name
R5
115_REFCLK1_N
AC29
213_REFCLK0_P
AC30
213_REFCLK0_N
AA29
213_REFCLK1_P
AA30
213_REFCLK1_N
W29
214_REFCLK0_P
W30
214_REFCLK0_N
U29
214_REFCLK1_P
U30
214_REFCLK1_N
N29
215_REFCLK0_P
N30
215_REFCLK0_N
R29
215_REFCLK1_P
R30
215_REFCLK1_N
www.xilinx.com
Quad
Connector
115
213
213
213
213
214
214
214
214
215
215
215
215
VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
J86
J158
J158
J158
J158
J159
J159
J159
J159
J241
J241
J241
J241
