Installing the Cabinet on a Labconco Base Stand

Labconco offers accessory base stands in a variety of configurations to suit your
particular needs. If assembly of the base stand is required, the assembly
instructions are packaged with the base stand.

Telescoping Base Stands

These stands are included with some cabinet models, or available separately. The
base stands are listed in Table 3-1 below. An optional caster wheel kit is available
(catalog number 3730500).
Note: B2 biosafety cabinets MUST be connected to an exhaust system, if ordering
the caster wheel kit, the duct connection MUST be of flexible construction.

Manual or Electric Hydraulic Lift Base Stands

These base stands offer infinitely adjustable height between 25.5 and 33.5 inches
(648 to 851 mm), giving a cabinet work surface height of 28.0 to 36.0 inches. The
height is adjusted either manually (hand crank) or electric pump that drives the
hydraulic legs of the stands. All of the hydraulic stands are equipped with fixed
feet, but can be converted to caster wheels with the Caster Kit (catalog number
3784000). The base stands for each cabinet size are listed in Table 3-2 below.
Cabinet
Manual Lift Stand
Width
Catalog Number
(Feet)
4'
6'
Note: When installing the cabinet on the hydraulic lift base stand, ensure that the
hydraulic lines and the electrical cord are clear of any obstructions before installing
the cabinet on the stand or operating the lift system.
Note: B2 biosafety cabinets MUST be connected to an exhaust system, if ordering
an adjustable height stand, the duct connection MUST be of flexible construction.
3: Getting Started
Cabinet Width
(Feet)
4'
6'
Electric (100-115V) Lift
Stand Catalog Number
3780201
3780202
Table 3-1
Base Stand Catalog
Number
3401004
3401006
Electric (230V) Lift
Stand Catalog Number
3780101
3780102
Table 3-2
3780104
3780105
