Specifications

Model
Power connector M12 (5 pin) plug
Control, input
power supply
Output power
Enclosure
Operating temp.
Operating humidity
Withstand voltage
Insulation
resistance
Vibration resistance
Impact resistance
Standard
Outline dimensions
EX600-ED2
EX600-ED2
24 VDC ±10 %
Maximum 2 A
24 VDC +10 % / -5 %
supply Maximum 2 A
range
range
500 VAC for 1 minute between external terminals and FE
500 VDC, Min. 10 MΩ between external terminals and FE
10 ~ 57 Hz with constant amplitude of 0.75 mm p-p
57 ~ 150 Hz with constant acceleration of 49 m/s
for 2 hours in each direction of X, Y and Z direction (during
2
147 m/s 3 times in each direction of X, Y and Z (during de-energizing)
Weight
85.1
IP67 (manifold assembly)
-10 ~ 50
35 ~ 85 %RH (no dew condensation)
de-energizing)
CE marking, UL recognition (CSA)
170 g
20.5 5.5
- 44 -
EX600-ED3
7/8 inch (5 pin) plug
24 VDC ±10 %
Maximum 8 A
24 VDC +10 % / -5 %
Maximum 8 A
o
C
2
175 g
No.EX##-OML0007
