SMC Networks EX600-SDN Series Operation Manual page 71

Analog input unit object (6Dh)
Instance attribute
Attribute ID Access
112 Get/Set
116 Get/Set
117 Get/Set
164 Get/Set
165 Get/Set
168 Get/Set
169 Get/Set
172 Get/Set
Name
Monitor short circuit
Monitor over range
Monitor under range
Ch 0 input filter
Ch 1 input filter
Ch 0 range
Ch 1 range
Data format
Type Value
BOOL
BOOL
BOOL
UINT CH 0
UINT CH 1
UINT CH 0
UINT CH 1
USINT
- 71 -
0=Disable
1=Enable
0=Disable
1=Enable
0=Disable
1=Enable
0 = None
1 = 2 value average
2 = 4 value average
3 = 8 value average
0 = None
1 = 2 value average
2 = 4 value average
3 = 8 value average
0 = -10...+10 V
1 = -5...+5 V
2 = -20...+20 mA
3 = 0...10 V
4 = 0...5 V
5 = 1...5 V
6 = 0...20 mA
7 = 4...20 mA
0 = -10...+10 V
1 = -5...+5 V
2 = -20...+20 mA
3 = 0...10 V
4 = 0...5 V
5 = 1...5 V
6 = 0...20 mA
7 = 4...20 mA
0=Offset binary
1=Sign & magnitude
2=2's complement
No.EX##-OML0007
